INVENTORY

Listing of RCD’s most popular stock items, numerous additional items and values are available.

Series MC Thick Film Chip Resistors

MC0402	1Ω – 1 Meg, 1% (E-96 values) 10Ω – 1 Meg, 5% (E-24 values)
MC0603	10Ω – 1 Meg, 1% (E-96 values) 10Ω – 1 Meg, 5% (E-24 values)
MC0805	10Ω – 1 Meg, 1% (E-96 values) 10Ω – 1 Meg, 5% (E-24 values)
MC1206	10Ω – 1 Meg, 1% (E-96 values) 10Ω – 1 Meg, 5% (E-24 values)

Series BLU Precision Chip Resistors

BLU0402	10Ω to 100K, 0.1%
BLU0603	10Ω to 100K, 0.01% & 0.10%
BLU0805	10Ω to 1 Meg, 0.01% & 0.10%
BLU1206	10Ω to 1 Meg, 0.01% & 0.10%

Series CN Chip Resistor Arrays

CN1206A

10Ω to 10K 5% (E-24 values)

Series GP Metal Film Resistors 1%

GP50, 1/8W, 1%	10Ω to 1 Meg (E-96 values)
GP55, 1/4W, 1%	10Ω to 1 Meg (E-96 values)
GP55S, 1/2W, 1%	10Ω to 1 Meg (E-96 values)

Series CF Carbon Film Resistors 5%

CF12, 1/8W	1Ω – 1 Meg (E-24 values)
CF22, 1/4W mini	1Ω to 1 Meg (E-24 values)
CF25, 1/4W	1Ω to 22 Meg (E-24 values)
CF50S, 1/2W	1Ω to 10 Meg (E-24 values)
CF100, 1W	1Ω to 10 Meg (E-12 values)
CF200S, 2W	1Ω to 10 Meg (E-24 values)

Series RSF Power Oxide Resistors

RSF1A, 1W	0.10Ω to 100K (E-24 values)
RSF2B, 2W-3W	0.10Ω to 100K (E-24 values)
RSF3B, 5W	0.20Ω to 100K (E-24 values)

Series RMF Mini Power Oxide Resistors

RMF1/2, 1/2W	0.1Ω to 100K (E-24 values)
RMF1, 1W	0.08Ω to 120K, 1% &5%
RMF2, 2W	0.10Ω to 100K, 1% & 5%
RMF3, 3W	0.10Ω to 200K, 1% & 5%

Series 100 Wirewound Resistors 1% & 5%

125, 1W	0.10Ω to 1K (E-24 values)
135, 3W	0.01Ω to 10K (E-24 values)
160, 5W	0.05Ω to 10K (E-24 values)
175, 10W	0.10Ω to 1K (E-24 values)

Series 600 Heat-Sink WW Resistors 1% & 5%

615, 25W	0.05Ω to 1K (E12 values)
620, 50W	0.05Ω to 10K (E12 values)

Active & Passive Delay Lines

A1405 Active	5-tap, 25nS to 300nS
P1410 Passive	10-tap, 100nS to 500nS

Zero-Ohm Jumpers, SMD & Thru-Hole

ZJ1 ZJ2 ZJ3	Zero-ohm axial jumper
Z22	Zero-ohm uninsulated jumper
ZCF12 ZCF25S	Zero-ohm MELF jumper
ZJ1206	Zero-ohm high current SMD
ZC0402 ZC0603 ZC0805 ZC1206 ZC1210	Zero-ohm chip jumper

Series PW & PV Power Resistors 5%

PV5, 5W	0.01Ω to 100K, 5%
PW5, 5W	0.01Ω to 100K, 5% & 10%
PW10, 10W	0.01Ω to 100K, 5% & 10%

Series RG High Meg Ohm Resistors

RG1/4, 500V	1M to 1000M, 1% & 5%
RG1/2, 1KV	1M to 1000M, 1% & 5%

Series CC Carbon Composition Resistors

CC1/4, 1/4W	1Ω – 22M, 5% & 10%
CC1/2, 1/2W	1Ω – 6.8M, 5% & 10%
CC1, 1W	2.2Ω – 1M, 10%

Series CL SIP Resistor Networks

CL06, Config 1 & 2	33Ω to 1 Meg (E-6 values)
CL08, Config 1 & 2	10Ω to 1 Meg (E-6 values)
CL10, Config 1 & 2	10Ω to 1 Meg (E-6 values)

Series CE Ceramic Chip Capacitors

CE0402	0.47pF – 0.1µF, C0G, X7R, Y5V
CE0603	10pF – 1µF, C0G, X7R, Y5V
CE0805	10pF – 10µF, C0G, X7R, Y5V
CE1206	10pF – 10µF, C0G, X7R, Y5V

Series TS Tantalum Chip Capacitors

TSA (1206)	0.10µF to 22µF
TSA (1411)	1µF to 47µF
TSA (2412)	10µF to 100µF
TSA (2917)	10µF to 100µF

Series MCI Chip Inductors

CI0603	0.01µH to 0.1µH (E12 values)
CI0805	0.01µH to 1µH (E12 values)
CI1008	0.01µH to 10µH (E12 values)
MCI1210	0.01µH to 330µH (E-6 values)
MCI1812	0.10µH to 1,000µH (E12 values)

Series AL, P & PF Inductors

AL02, 10%	0.1µH to 470µH (E-6 values)
AL03, 10%	0.1µH to 470µH (E-6 values)
AL05, 10%	0.1µH to 2200µH (E-6 values)
P0206, 10%	0.1µH – 1000µH, molded (E-12)
PF0410, 10%	0.22µH – 10,000µH, shielded (E-12)
